RWD Life Science

Small animal ventilator

Code R407RWD
Equipped with high quality motor, speed reducer and controller, RWD’s ventilator with low noise, precisely control and durable. They could be run separately with air or oxygen as the gas source, or together with anesthesia machine for improving the anesthetic effect. The Model R407 Small Animal Ventilator comes standard with two piston and cylinder assemblies.
Read more about product
See other products in applications
Features
  • Classic capacitive control mode, fine motor control, safe and stable
  • The piston travels to the end of the cylinder completely emptying the cylinder
  • minimizing the dead space of the breathing circuit.
  • Respiratory rates: 18 – 150 strokes /minute
  • The smaller piston allows Tidal volumes: 0.5to 5.0cc in 0.5cc increments
  • The larger cylinder allows Tidal volumes: 3.0 to 30cc in 0.3cc increments
Specifications
  • Used for rats, hamsters, rabbits, cats, monkeys, small dogs from 200 g to 50 kg
  • Respiratory rates: 18 – 150 strokes /minute
  • The smaller piston allows Tidal volumes: 0.5to 5.0cc in 0.5cc increments
  • The larger cylinder allows Tidal volumes: 3.0 to 30cc in 0.3cc increments
  • Numerical LED displays the respiratory rate
  • Volume and rate setting can be adjusted while the ventilator is running
  • Monitor and control PEEP (positive end expiratory pressure) by attaching the ventilator exhaust to a column of water, when long term animal ventilation is required.
  • Volume and speed controlled by the linear mode
Components
Standard system components
  • R407 Including Ventilator, connecting silicon tube and trachea cannula (14G)- 1.85mm OD
  • R407V Including Ventilator, connecting silicon tube and trachea cannula (14G)- 1.85mm OD
