Extraction water bath, 8 chambers, up to 100°C
Code DH.WEB01008
The WEB-8 extraction water bath offers the highest capacity with eight extraction positions and a double heating system (2 x 1400 W), making it ideal for demanding, high-throughput laboratory environments. Its enlarged inner length (290 mm) allows for larger or multiple vessels. Advanced safety features, including low water level warning and automatic stop, ensure reliable and safe operation.
Read more about product
See other products in applications
Features
Ideal for
- Gentle extraction, Soxhlet extraction and determination of COD
Features
- Available with 8 extraction chambers
- User‘s self-compensation function to control difference between real temperature and indicated temperature (±10.0°C)
- Concentric ring cover set Ø 110 mm and stainless steel holding frame included, drain valve mounted
- Stainless steel interior and powder-coated steel body
- Storage function for the set values of temperature and timer
- Backlight LCD display
- CE certified and unique serial number for tracing
Safety mechanism
- Overheat and over-current protection
- Sensor error detection
- Locking mode
- Low water level warning and automatic stop function
Controller
- Digital fuzzy controller with Jog-Shuttle-switch (turn + push)
Specifications
- Width (inner): 610 mm
- Length (inner): 290 mm
- Height (inner): 160 mm
- Width (Outer): 720 mm
- Length (outer): 375 mm
- Height (outer): 275 mm
- Weight with packaging: 34 kg
- Power consumption: 2 x 1400 W
- Temperature range: Room temperature +5°C - 100°C
- Temperature fluctuation: ±1.0°C
- Temperature accuracy: ±0.2°C
- Packing size: 880 x 420 x 300 mm
- Controller: Temperature sensor PT100
