witeg
Bath circulation head 22l, 100°C
Code DH.WCB10022
This version offers a larger capacity, making it suitable for applications that require processing higher sample volumes. It maintains the same high level of temperature precision and pump performance as the smaller model. The robust construction and advanced digital control guarantee consistent and safe operation even with increased workloads.
Read more about product
See other products in applications
Features
- Self-regulation function to control difference between real temperature and indicated temperature (±10.0°C)
- Digital timer function (99hr 59min): Delay time and operation time can be controlled
- Powerful circulation pump assures temperature uniformity
- Storage function for the set values of temperature and timer
- Backlight LCD display
- CE certified and unique serial number for tracing
- Safety mechanism:
- Locking mode
- Over-temperature and over-current protection
- Sensor error detection
- Low water level warning and automatic stop function
- Controller: Digital fuzzy controller with Jog-Shuttle-switch (turn + push)
Specifications
- Width (Outer): 130 mm
- Length (outer): 165 mm
- Height (outer): 320 mm
- Weight with packaging: 10 kg
- Capacity: 11 l
- Pump performance: 5 l/min
- Power consumption: 1000 W
- Temperature range: Room temperature +5°C - 100°C
- Temperature accuracy: ±0.1°C
- Packing size: 400 x 280 x 200 mm
- Controller: Temperature sensor PT100
